TENDA 1000M & PoE 16-PORT Gigabit Desktop/Rackmount Switch

Hardware Features

Product Model TEG1116P-16-150W v1.0

Interface 16 10/100/1000Base-T ports(Data/Power)

Port Lightning Protection 6KV

Store and forward Yes

Exchange Capacity 32 Gbps

Packet forwarding rate 23.6Mpps

MAC Address Table 8K

PoE supply management Port 1-16 support IEEE802.3at/af PoE standard

PoE through pin 1 2 4 5 +;3 6 7 8 -

Voltage input range AC• •100-240V～50/60Hz

Dimensions ( W x D x H ) 294*178*44mm

Power Consumption PoE Max Power Supply:135W

Port Features Standard:  the switch functions as a common unmanaged switch and all the
ports of the switch can communicate with each other.
CCTV: the port cache is optimized and PoE ports 1-8 have higher priorities
over the other ports. All the ports of the switch can communicate with each
other.
VLAN: ports 1 to 14 are isolated from each other, but can communicate with
ports 15 and 16 (uplink ports) respectively.
Environment

Operating Temperature: 0℃~40℃ (32℉~104℉)

Storage Temperature: -40℃~70℃ (-40℉~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

Standard&Protocol IEEE 802.3/IEEE 802.3u/IEEE 802.3ab/IEEE 802.3x/
IEEE 802.3af/IEEE 802.3at
Indicator

16*Link/Act per device
